| Quantity: | |
|---|---|
59.63cm*20.55cm*62.05cm
CAMC
| Power | 20kW/30kW |
| Model | DC (Single gun) |
| Connector | GBT/CCS1/CHAdeMO/CCS2 |
| Max Power | 30kW |
| Emergency Stop Button | Yes |
| Communication Protocol | OCPP1.6J Or other |
| Input Voltage | 380V (-25%,+25%) AC |
| Frequency | 50Hz+ 10% |
| Output Voltage | 50V~ 1000VDC |
| Protection Grade | IP54 |
| Power distribution | Single gun |
| Power factor | 20.99 |
| Peak efficiency | 95.5% |
| Overall efficiency | 94% |
| axiliay power supply | 12V |
| humidness | ≤95% |
| Soft startup time | 3-8s |
| Output voltage error | ≤+0.5% |
| Output current error | ≥30A ，≤+1%; <30A ，≤+0.3A |
| Voltage accuracy | ≤0.5% |
| Steady flow accuracy | ≤1% |
| Voltage ripple | ≤1% |
| Current sharing | ≤5% |
| Load adjustment rate | ≤1% |
| Emc | GB/T 19826-2014: 5.4 |
| Starting mode | Swipe card/small program scan code |
| Insulation resistance | ≥10MΩ |
| Withstand voltage | AC2500V |
| Display screen | 7 inch touch screen |
| istallation mode | Floor/wall hanging |
| Operating temperature | -35°C~ +55℃ |
| Charging gun length | 3m/4m/5m |
| Altitude | ≤2000m (customization required for altitudes above 2000m) |
| Outer dimension | 596.3mm*205.5mm*620.5mm |
| Harmonic distortion | ≤5% |
The product has a wide range of uses, suitable for small areas, shopping malls, office buildings, outdoor parking lots and other places, from private vehicles to public transportation,from large goods to engineering vehicles, etc. All types of vehicle charging.
High-efficiency：
Output new rectifier module technology, power factor up to 99%, efficiency up to 95%, wide voltage range
Super compatible：
Integrate Ethernet, 4G communication, can communicate with the background at any time, support multi-platform, compatible with multi-brand modules
Wide range of applications：
It is used in various scenarios such as residential areas, bus stations, factories, etc., and is suitable for various types of cars, buses, etc.
CAMC is a professional company operating in the vehicles and transportation industry. Our company is the national priority production and research development base of heavy trucks, special purpose heavy vehicles and spare parts, which is also the state mainly supports enterprise., including various models such as 4*2, 6*4, 8*4, and more, to meet the diverse needs of our clients.
located in Maanshan Economic and Technology Development Zone, Anhui, China, CAMC was found in 1970s and we are the only truck enterprise in China which is capable of producing everything on our own including engine, gearbox, axles, chassis, cabin and so on.
Our company is specialized in different kinds of products which can meet your multifarious demands. We adhere to the management principles of "quality first, customer first and credit-based" since the establishment of the company and always do our best to satisfy potential needs of our customers.
Our company is sincerely willing to cooperate with enterprises from all over the world in order to realize a win-win situation since the trend of economic globalization has developed with an irresistible force.
Q:Which vehicles is this DC charging column suitable for?
A:Widely used for charging cars, engineering vehicles, logistics vehicles, sanitation vehicles and other vehicles.
Q:What networking methods are supported?
A:Support 4G, Ethernet networking.
Q:What are the protection functions？
A:Short circuit, over current, over temperature, leakage, over voltage, etc.
Q:What are the charging modes？
A:Automatic charging, by time, by battery, by amount.
Q:How to start the charging pile？
A:Swipe IC card, WeChat, scan code, VIN, password.
Q:How long is the warranty？
A:Warranty 1 year. If you need to increase the warranty: 3% in the second year, 4% in the third year, 5% in the fourth year, and 8% in the fifth year.
Q:Are there other types and series of charging piles?
A:We have a full-scene, full-category charging pile product system, such as H series AC charging piles, X series AC charging piles, L series DC charging piles, T series AC charging piles, etc., to meet your diverse needs.
Q:How about the delivery time?
A:One to two months. Normally we need around 25 days for production.
Q:How about your product after-sales service system?
A:Our main export countries have accepted after-sales service, some countries use the third party service.
Q:Do you accept custom order? What's is your MOQ order?
A:Yes, we do. Our MOQ is 1 unit.
Q:why should you buy from us not from other suppliers?
A:CAMC was found in 1970s and we are the only truck enterprise in China which is capable of producing everything by our own including engine, gearbox, axles, chassis, cabin and so on.
Our company is specialized in different kinds of products which can meet your multifarious demands. We adhere to the management principles of "quality first, customer first and credit-based" since the establishment of the company and always do our best to satisfy potential needs of our customers.
